PC3005350U, PC Module for Industrial Display System
- Intel® i5-5350U, up till 2.9GHz
- 1x 204-pin DDR3L SODIMM. max up till 8GB
- 1x 2.5” SATA HDD bay support RAID 0,1, 5, 2x mSATA,
- 2x SIM socket 2x full-size mini PCIe for communication or expansion modules
- 2x LAN, 1x VGA, 1x DisplayPort 4x RS-232/422/485 (w/ 2x internal),
- 3x USB 3.0, 1x USB 2.0,
- Audio, DIO 9 till 48VDC wide range power input
- -40°C till 70°C extended operating temperature
